H216
Forestry Attachments, Accessories and Implements
Overview:
The H216 Harvester Head from John Deere provides unmatched precision and high efficiency in timber harvesting, featuring advanced technology for improved productivity and reduced operator fatigue.
- All Greasing Points Accessible in One Position
- For All Types of Wood
- Excellent Productivity, Amount of Cutting Cracks Minimized
- Saw Bars up to 3 ft (90 cm) can be Used
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Share This Product:
Features
Short Service Time
Short daily service time. All greasing points accessible in one position makes maintenance quick and easy. Easy saw chain change.
Good Delimbing Quality
Good delimbing quality. Excellent productivity and amount of cutting cracks minimized. Saw bars up to 90 cm can be used. The H216 can be equipped for debarking application. Debarking feed rollers with length measuring and a dedicated, detachable debarking tool in the frame make the H216 suitable for temporary debarking needs.
For All Types Of Wood
Good measuring accuracy and high productivity also with hardwood. The H216's frame, tilt, roller arms and design of the knives make tree-handling effortless. Multi-tree-handling equipment also available. The frame is high and gives excellent support to a bunch of trees.
Specifications
Feed System, Two-Wheel-Drive
| Maximum Feed Speed | 4,2-6,3 m/s |
| Maximum Feed Speed | 13.8-20.7 fps |
| Maximum Roller Opening | 700 mm |
| Maximum Roller Opening | 26 in. |
Delimbing
| Delimbing Knives | 4 moving and 1 fixed |
| Delimbing Diameter, Tip To Tip | 450 mm |
| Delimbing Diameter, Tip To Tip | 18 in. |
| Maximum Opening Upper Knives | 700 mm |
| Maximum Opening Upper Knives | 28 in. |
| Maximum Opening Lower Knives | 760 mm |
| Maximum Opening Lower Knives | 30 in. |
Hydraulic System
| Maximum Operating Pressure | 28/35 (option) MPa |
| Maximum Operating Pressure | 4061/5076 (option) psi |
| Recommended Pump Capacity | 260-370 L/min |
| Recommended Pump Capacity | 68.7-97.7 gpm |
Felling/Cutting
| SuperCut 100S Saw Unit, Automatic Chain Tensioning | Standard, Top Saw |
| Maximum Cut Diameter | Standard: 750 Top Saw: 400 mm |
| Maximum Cut Diameter | Standard: 29.5 Top Saw: 15.7 in. |
| Length Of Saw Bar | Standard: 900; Top Saw: 600 mm |
| Length Of Saw Bar | Standard: 35.4; Top Saw: 23.6 in. |
| Chain Type | 404 |
| Chain Speed | 40 m/s |
| Chain Speed | 131 fpm |
Dimensions
| Width, Head Open | 1695 mm |
| Width, Head Open | 67 in. |
| Width, Head Closed | 1335 mm |
| Width, Head Closed | 52.6 in. |
| Height Without Rotator and Link | 1845 mm |
| Height Without Rotator and Link | 72.6 in. |
| Weight Without Rotator and Link | 1490 kg |
| Weight Without Rotator and Link | 3285 lb. |
Optional Equipment
| Stump Treatment | Yes |
| Multi-Tree-Handling (MTH) | Yes |
| Mense Feed Rollers | Yes |
| Steel Thumbnail Feed Rollers | Yes |
| Steel Ribbed Feed Rollers | Yes |
| Chain And Saw Bar Kits | Yes |
| Hydraulic Hose Kit | Yes |
| Top Saw | Yes |
Tank Capacities
| Color Marking | 1.4 L |
| Color Marking | Yes |
| Color Marking | 0.37 gal. |
| Chain Oil | 14 L |
| Chain Oil | 3.7 gal. |
| Chain Grease | 1.2 kg |
| Chain Grease | 2.6 lb. |
