John Deere FR22B

New Products / John Deere / John Deere Products / Forestry Equipment / Forestry Attachments, Accessories and Implements / FR22B

Double tap to zoom



Features

Handle a Wide Range of Timber

John Deere tracked forestry machine lifts and processes felled logs with a harvesting head in a dense pine forest, with cut timber in the foreground and tall trees surrounding the work area.

Take on both mid-sized and larger trees with a versatile design built for varied forestry applications.

Balance Power and Efficiency

John Deere tracked forestry machine uses a harvesting head to grip and cut a tree in a lightly snow-covered forest, surrounded by tall pines, scattered brush, and freshly cut wood debris.

Maintain strong cutting force and accumulation performance for consistent productivity across cycles

Built to Fit Your Operation

John Deere tracked forestry machine cuts a tree with a harvesting head, sending wood chips outward, in a dense forest with fallen logs and debris covering the ground.

Match machine performance to your job with limited or high-rotation configurations.

Specifications

Dimensions

Maximum Cutting Capacity22 in.
Maximum Cutting Capacity559 mm
Maximum Accumulation Capacity5.2 sq ft
Maximum Accumulation Capacity56 m²
Opening At Front Of Housing50.4 in.
Opening At Front Of Housing1280.2 mm
Blade Diameter56 in.
Blade Diameter1422.4 mm
Number Of Teeth15
Saw Speed1150 rpm
Wrist Rotation312 degree (angle)
Width At Saw Housing63.8 in.
Width At Saw Housing1620.5 mm
Height120.5 in.
Height3060.7 mm
Weight Measure Inclusions Or ExclusionsAdapter and wrist
Weight8470 lb.
Weight3842 kg
